Mic Input
|
|
Frequency Response
|
22Hz to 20kHz (+/-0.2dB)
|
|
Dynamic Range
|
90dB, A-weighted
|
|
Signal-to-Noise Ratio
|
-90dB, A-weighted
|
|
THD+N
|
<0.0061% (-86dB)
|
|
Crosstalk
|
-85dB @ 1kHz
|
|
Input Impedance: Mic in
|
1.8K Ohms, typical
|
|
Adjustable Gain
|
+39dB
|
|
Inst Input
|
|
Frequency Response
|
22Hz to 20kHz (+/-0.2dB)
|
|
Dynamic Range
|
90dB, A-weighted
|
|
Signal-to-Noise Ratio
|
-90dB, A-weighted
|
|
THD+N
|
<0.0061% (-86dB)
|
|
Crosstalk
|
-75dB @ 1kHz
|
|
Input Impedance: Inst in
|
500K Ohms, typical
|
|
Total Gain Range
|
+38dB
|
|
Line Inputs (RCA IN, Unbalanced)
|
|
Frequency Response
|
22Hz to 20kHz (+/-0.2dB)
|
|
Dynamic Range
|
90dB, A-weighted
|
|
Signal-to-Noise Ratio
|
-90dB, A-weighted
|
|
THD+N
|
<0.003% (-86dB)
|
|
Crosstalk
|
-90dB @ 1kHz
|
|
Input Impedance
|
10K Ohms, typical
|
|
Adjustable Gain
|
+8dB
|
|
Line Outputs 1/2 (Stereo, Unbalanced)
|
|
Frequency Response
|
22Hz to 20kHz (+/-0.2dB)
|
|
Dynamic Range
|
90dB, A-weighted
|
|
Signal-to-Noise Ratio
|
-90dB, A-weighted
|
|
THD+N
|
<0.003% (-86 dB)
|
|
Crosstalk
|
-90dB @ 1kHz
|
|
Nominal Output Level
|
Unbalanced: +2dBV, typical
|
|
Headphone Outputs: (at Maximum Volume; Into 100 Ohm load)
|
|
Frequency Response
|
22Hz to 20kHz (+/-0.2dB)
|
|
Power into Ohms
|
20 mW into 100 Ohms
|
|
THD+N
|
<0.06% (-66dB)
|
|
Signal-to-Noise Ratio
|
-90dB, A-weighted
|
|
Max Output Level into 100 Ohms
|
+2.0dBV, typical
|
|
Load Impedance
|
32 to 600 Ohms
|
